Product Overview

In aluminum profile anodizing processes, clamps are not only used for fixing profiles but also play an important role in positioning accuracy, electrical contact consistency, and automated production efficiency.

Traditional manual clamps may experience differences caused by operator handling, clamping force variation, and frequent profile size changes. These factors can affect production repeatability in continuous anodizing lines.

The KRT-085 Pneumatic Anodizing Clamp is designed for aluminum profile surface treatment applications. It combines the functions of a pneumatic clamp and anodizing fixture, using pneumatic control to achieve automatic clamping and releasing operations.

With a compact structure, the KRT-085 features a 120mm overall length, 17mm static opening, and 78mm maximum opening, making it suitable for aluminum anodizing lines requiring flexible and automated clamping solutions.

Problem

Clamping Challenges in Automated Anodizing Lines

During aluminum anodizing production, clamps must operate continuously under chemical treatment environments and repeated production cycles.

1. Manual Operation Affects Clamping Consistency

Manual clamps rely on operators to control opening and closing actions.

Different operation habits may cause variations in positioning and clamping conditions.

2. Different Profile Sizes Require Flexible Clamping Range

Aluminum extrusion profiles are available in various shapes and dimensions.

A fixed-size clamp may not meet different production requirements, resulting in frequent fixture replacement.

3. Automated Lines Require Controlled Clamping Actions

Modern anodizing lines require clamps that can integrate with automatic equipment systems.

The clamp must support repeatable opening and closing operations through machine control.

Cause

Why Standard Clamps May Not Meet Automation Requirements

Anodizing clamps need to consider more than mechanical holding. They must support positioning accuracy, production rhythm, and equipment compatibility.

Important factors include:

1. Opening Range

The clamp opening determines profile compatibility.

The KRT-085 provides a 78mm maximum opening, allowing greater flexibility for different aluminum profile sizes.

2. Compact Installation Design

Production equipment often has limited installation space.

The KRT-085 features a 120mm overall length, supporting compact equipment integration.

3. Repeatable Pneumatic Operation

Pneumatic control allows production equipment to manage clamping actions consistently during continuous operation.

Solution

KRT-085 Pneumatic Anodizing Clamp Technical Solution

The KRT-085 provides a solution for automated aluminum surface treatment lines by combining pneumatic operation with anodizing fixture design.

Pneumatic Control Structure

The clamp uses pneumatic operation to achieve controlled opening and closing actions.

This design is suitable for automated production systems requiring repeated clamping cycles.

Compact 120mm Design

The KRT-085 has an overall length of 120mm.

The compact structure helps optimize installation space in anodizing equipment.

17mm Static Opening

The 17mm static opening provides a defined initial clamping position for aluminum profiles.

78mm Maximum Opening

The 78mm maximum opening improves adaptability for different aluminum profile dimensions during surface treatment operations.

KRT-085 Specification Table

Application

Aluminum Profile Anodizing Lines

The KRT-085 is mainly used for aluminum profile anodizing production, supporting automatic clamping and positioning operations.

Typical applications include:

Automatic Anodizing Production Lines

Suitable for production systems requiring continuous loading, clamping, and releasing operations.

Aluminum Extrusion Processing Factories

Used in aluminum profile manufacturers producing industrial and architectural extrusion products.

Surface Treatment Equipment

Applicable for processes requiring automated fixture positioning.

How to Choose a Pneumatic Anodizing Clamp

1. Select According to Profile Size

Confirm the maximum profile dimension before selecting the clamp.

For applications with multiple profile sizes, a larger opening range is recommended.

The KRT-085 provides a 78mm maximum opening for flexible profile compatibility.

2. Consider Equipment Installation Space

Compact fixture dimensions are important for automated equipment integration.

The KRT-085 features a 120mm overall length for space-efficient installation.

3. Choose According to Production Method

Manual production lines may use manual clamps.

Automated anodizing lines are better suited for pneumatic clamps controlled by production equipment.

FAQ

Q1: What industries use the KRT-085 Pneumatic Anodizing Clamp?

The KRT-085 is mainly used in aluminum profile anodizing lines, electrophoresis lines, and industrial surface treatment systems requiring automatic clamping.

Typical users include aluminum extrusion manufacturers and surface treatment factories.

Q2: What is the maximum opening of the KRT-085 clamp?

The KRT-085 features a 78mm maximum opening.

The actual suitable profile size depends on profile design, contact position, and production requirements.

Q3: Why are pneumatic clamps preferred for automated anodizing lines?

Pneumatic clamps allow equipment-controlled opening and closing actions.

They are suitable for continuous production environments requiring repeatable clamping operations.

Q4: Can the KRT-085 be customized?

Yes.

The clamp structure, installation method, and clamping dimensions can be customized according to specific production line requirements.
